40HP 8.3M3/Min Single Phase Screw Compressor For Atlas Copco

Certification
China Wuxi WOYO Superdo Compressor Co.,Ltd certification
China Wuxi WOYO Superdo Compressor Co.,Ltd certification
I'm Online Chat Now

40HP 8.3M3/Min Single Phase Screw Compressor For Atlas Copco

40HP 8.3M3/Min Single Phase Screw Compressor For Atlas Copco
40HP 8.3M3/Min Single Phase Screw Compressor For Atlas Copco

Large Image :  40HP 8.3M3/Min Single Phase Screw Compressor For Atlas Copco

Product Details:
Place of Origin: CHINA
Brand Name: WOYO
Certification: CE,ISO,UL
Model Number: GCU-M
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: USD900-2200
Packaging Details: PLYWOOD CASE
Delivery Time: 10-30 days
Payment Terms: T/T, L/C
Supply Ability: 100 unit/Month

40HP 8.3M3/Min Single Phase Screw Compressor For Atlas Copco

Description
Warranty: 12-18 Month Power: 10-60HP
Type: Screw Advantage: Low Noise, Easy For Maintain
Color: Gray Or Yellow Characteristic: Mechanical Seal For GAS Applications
High Light:

8.3M3/min single phase screw compressor

,

40HP single phase screw compressor

,

Atlas Copco portable screw compressor



10hp-60hp Screw Air Compressor Rotor Head Airend Air End Spare Parts For Atlas Copco



Compact Screw Airend Features


1. Built-in three sets of crude oil air separation device, to solve the problem of oil consumption
2. More convenient maintenance
3. Smaller size and Low noise
4. We not only provide compact unit,but also can be customized



Compact Screw Airend Parameters



Type Power Range(Hp) Pressure(Bar) Capacity(M3/min) Speed Range(RPM) Net Weight(KG)
GCU10 From 7.5hp-10hp 7-13 0.48-1.16 2950-3950   40

GCU13 15hp 7-13 1.15-1.8 4660-6100 75

GCU30 From 20hp-30hp 7-13 1.75-3.6 2950-5500   140

GCU33 From 20hp-30hp 7-13 1.75-3.5 2850-5100  137

GCU55 From 40hp-60hp 7-13 4.2-8.3 3000-6500  190




Compact Screw Airend Advantages



More than 40 years of experience in theory and practice of screw compact unit, the engineers of WOYO focus on special screw airends and modules of green intelligent screw air compressor R&D and manufacturing. For saving energy, reducing emission and protecting environmental,create more value for customers in three aspects. More green protection for the Earth.



1. The Profile: According to WOYO and German & Italian partner rotor profile levels of energy efficiency standards for new optimization,also can guarantee good performance even in extreme conditions.

2. Rotor Grinding: German Kapp and Italian SU grinding machine are processing and checking.

3. Bearing: Use SKF or NTN high quality thrust and radial bearing.

4. Shaft seal/Sleeve: Famous German brand lip seal/sleeve.

5. Driving model: 2P 1:1 direct driven or belt driven.



Our Company Service



1. We have own developing and designing team, which ensure our own technological and innoative products for customers.

2. For any customers who send us the samples of rotors or airend, we will design and develop better ones based on the samples.

3. We are manufacturer, factory, so we have the ability of mass production.


Technical Support:

Most of our WOYO products adopt German advanced technilogy, and the producing machine are all equipped with German and Japan.


After Sale Service:

Our working team will always reply you if you need any technical support and help, we can use video, whatsapp and other commication tools to help
